box.c File Reference

#include "box.h"
#include <stdint.h>
#include <string.h>
#include "libbase/libbase.h"
#include "container.h"
#include "rectangle.h"

Include dependency graph for box.c:

Functions
static void	_wlmtk_box_element_layout (wlmtk_element_t *element_ptr)
static bs_dllist_node_t *	create_margin (wlmtk_box_t *box_ptr)
static void	_wlmtk_box_margin_set_color (bs_dllist_node_t *dlnode_ptr, void *ud_ptr)
bool	wlmtk_box_init (wlmtk_box_t *box_ptr, wlmtk_box_orientation_t orientation, const struct wlmtk_margin_style *style_ptr)
void	wlmtk_box_fini (wlmtk_box_t *box_ptr)
void	wlmtk_box_add_element_front (wlmtk_box_t *box_ptr, wlmtk_element_t *element_ptr)
void	wlmtk_box_add_element_back (wlmtk_box_t *box_ptr, wlmtk_element_t *element_ptr)
void	wlmtk_box_remove_element (wlmtk_box_t *box_ptr, wlmtk_element_t *element_ptr)
wlmtk_element_t *	wlmtk_box_element (wlmtk_box_t *box_ptr)
void	wlmtk_box_set_style (wlmtk_box_t *box_ptr, const struct wlmtk_margin_style *style_ptr)
static void	test_init_fini (bs_test_t *test_ptr)
static void	test_layout_horizontal (bs_test_t *test_ptr)
static void	test_layout_vertical (bs_test_t *test_ptr)

Variables
static const wlmtk_element_vmt_t	box_element_vmt
static const bs_test_case_t	_wlmtk_box_test_cases []
const bs_test_set_t	wlmtk_box_test_set
static const struct wlmtk_margin_style	test_style

Detailed Description

Copyright

Copyright (c) 2026 Philipp Kaeser (kaese.nosp@m.r@gu.nosp@m.bbe.c.nosp@m.h) Copyright 2023 Google LLC

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at

https://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

Function Documentation

_wlmtk_box_element_layout()

void _wlmtk_box_element_layout ( wlmtk_element_t *  element_ptr )

static

Lays out the elements of the box.

Steps through all visible elements, and sets their position to be left-to-right. Also updates and repositions all margin elements.

Parameters

element_ptr

_wlmtk_box_margin_set_color()

void _wlmtk_box_margin_set_color ( bs_dllist_node_t *  dlnode_ptr, void *  ud_ptr  )

static

Sets the color in each margin rectangle.

create_margin()

bs_dllist_node_t * create_margin ( wlmtk_box_t *  box_ptr )

static

Creates a new margin element, and returns the dlnode.

test_init_fini()

void test_init_fini ( bs_test_t *  test_ptr )

static

Exercises setup and teardown.

test_layout_horizontal()

void test_layout_horizontal ( bs_test_t *  test_ptr )

static

Tests layouting horizontally

test_layout_vertical()

void test_layout_vertical ( bs_test_t *  test_ptr )

static

Tests layouting vertically

wlmtk_box_add_element_back()

void wlmtk_box_add_element_back	(	wlmtk_box_t *	box_ptr,
		wlmtk_element_t *	element_ptr
	)

Adds element_ptr to the back of the box.

Parameters

box_ptr
element_ptr

wlmtk_box_add_element_front()

void wlmtk_box_add_element_front	(	wlmtk_box_t *	box_ptr,
		wlmtk_element_t *	element_ptr
	)

Adds element_ptr to the front of the box.

Parameters

box_ptr
element_ptr

wlmtk_box_element()

wlmtk_element_t * wlmtk_box_element

(

wlmtk_box_t *

box_ptr

)

Returns

Pointer to the superclass' wlmtk_element_t of box_ptr.

wlmtk_box_fini()

void wlmtk_box_fini

(

wlmtk_box_t *

box_ptr

)

Un-initializes the box.

Parameters

box_ptr

wlmtk_box_init()

bool wlmtk_box_init	(	wlmtk_box_t *	box_ptr,
		wlmtk_box_orientation_t	orientation,
		const struct wlmtk_margin_style *	style_ptr
	)

Initializes the box with the provided virtual method table.

Parameters

box_ptr
orientation
style_ptr

Returns

true on success.

wlmtk_box_remove_element()

void wlmtk_box_remove_element	(	wlmtk_box_t *	box_ptr,
		wlmtk_element_t *	element_ptr
	)

Removes element_ptr from the box.

Requires that element_ptr is an element of the box.

Parameters

box_ptr
element_ptr

wlmtk_box_set_style()

void wlmtk_box_set_style	(	wlmtk_box_t *	box_ptr,
		const struct wlmtk_margin_style *	style_ptr
	)

Updates the box style and updates the layout of the contained elements.

Variable Documentation

_wlmtk_box_test_cases

const bs_test_case_t _wlmtk_box_test_cases[]

static

Initial value:

= {
    { 1, "init_fini", test_init_fini },
    { 1, "layout_horizontal", test_layout_horizontal },
    { 1, "layout_vertical", test_layout_vertical },

}

Test cases

box_element_vmt

const wlmtk_element_vmt_t box_element_vmt

static

Initial value:

= {
    .layout = _wlmtk_box_element_layout,
}

Virtual method table: wlmtk_element_t at wlmtk_box_t level.

test_style

const struct wlmtk_margin_style test_style

static

Initial value:

= {
    .width = 2,
    .color = 0xff000000
}

Style used for tests.

wlmtk_box_test_set

const bs_test_set_t wlmtk_box_test_set

Initial value:

= BS_TEST_SET(
    true, "box", _wlmtk_box_test_cases)

Unit tests.
