titlebar.c File Reference

#include "titlebar.h"
#include <cairo.h>
#include <libbase/libbase.h>
#include <libbase/plist.h>
#include <stdlib.h>
#include <wlr/interfaces/wlr_buffer.h>
#include "box.h"
#include "primitives.h"
#include "style.h"
#include "titlebar_button.h"
#include "titlebar_title.h"

Include dependency graph for titlebar.c:

Classes
struct	_wlmtk_titlebar_t

Functions
static void	_wlmtk_titlebar_element_destroy (wlmtk_element_t *element_ptr)
static void	_wlmtk_titlebar_compute_positions (wlmtk_titlebar_t *titlebar_ptr, const struct wlmtk_titlebar_style *style_ptr)
static bool	_wlmtk_titlebar_redraw_buffers (wlmtk_titlebar_t *titlebar_ptr, const struct wlmtk_titlebar_style *style_ptr, unsigned width)
static bool	_wlmtk_titlebar_redraw (wlmtk_titlebar_t *titlebar_ptr, const struct wlmtk_titlebar_style *style_ptr)
wlmtk_titlebar_t *	wlmtk_titlebar_create (wlmtk_window_t *window_ptr, const struct wlmtk_titlebar_style *style_ptr)
void	wlmtk_titlebar_destroy (wlmtk_titlebar_t *titlebar_ptr)
bool	wlmtk_titlebar_set_width (wlmtk_titlebar_t *tb, unsigned width)
bool	wlmtk_titlebar_set_style (wlmtk_titlebar_t *tb, const struct wlmtk_titlebar_style *style_ptr)
void	wlmtk_titlebar_set_properties (wlmtk_titlebar_t *titlebar_ptr, uint32_t properties)
void	wlmtk_titlebar_set_activated (wlmtk_titlebar_t *titlebar_ptr, bool activated)
bool	wlmtk_titlebar_is_activated (wlmtk_titlebar_t *titlebar_ptr)
void	wlmtk_titlebar_set_title (wlmtk_titlebar_t *titlebar_ptr, const char *title_ptr)
wlmtk_element_t *	wlmtk_titlebar_element (wlmtk_titlebar_t *titlebar_ptr)
static void	test_variable_width (bs_test_t *test_ptr)
static void	test_properties (bs_test_t *test_ptr)

Variables
const bspl_desc_t	wlmtk_titlebar_style_desc []
static const wlmtk_element_vmt_t	titlebar_element_vmt
static const uint32_t	_wlmtk_titlebar_default_properties
static const bs_test_case_t	_wlmtk_titlebar_test_cases []
const bs_test_set_t	wlmtk_titlebar_test_set

Detailed Description

Copyright

Copyright (c) 2026 Philipp Kaeser (kaese.nosp@m.r@gu.nosp@m.bbe.c.nosp@m.h) Copyright 2023 Google LLC

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at

https://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

Function Documentation

_wlmtk_titlebar_compute_positions()

void _wlmtk_titlebar_compute_positions ( wlmtk_titlebar_t *  titlebar_ptr, const struct wlmtk_titlebar_style *  style_ptr  )

static

Compute positions of the titlebar elements, if configured.

This method updates wlmtk_titlebar_t::close_position, wlmtk_titlebar_t::title_position and wlmtk_titlebar_t::title_width.

Parameters

titlebar_ptr
style_ptr

_wlmtk_titlebar_element_destroy()

void _wlmtk_titlebar_element_destroy ( wlmtk_element_t *  element_ptr )

static

Virtual destructor, wraps to our dtor.

_wlmtk_titlebar_redraw()

bool _wlmtk_titlebar_redraw ( wlmtk_titlebar_t *  titlebar_ptr, const struct wlmtk_titlebar_style *  style_ptr  )

static

Redraws the titlebar elements.

_wlmtk_titlebar_redraw_buffers()

bool _wlmtk_titlebar_redraw_buffers ( wlmtk_titlebar_t *  titlebar_ptr, const struct wlmtk_titlebar_style *  style_ptr, unsigned  width  )

static

Redraws the titlebar's background in appropriate size.

test_properties()

void test_properties ( bs_test_t *  test_ptr )

static

Tests titlebar with configured properties.

test_variable_width()

void test_variable_width ( bs_test_t *  test_ptr )

static

Tests titlebar with variable width.

wlmtk_titlebar_create()

wlmtk_titlebar_t * wlmtk_titlebar_create	(	wlmtk_window_t *	window_ptr,
		const struct wlmtk_titlebar_style *	style_ptr
	)

Creates a title bar, suitable as a window title.

Parameters

window_ptr
style_ptr

Returns

Pointer to the title bar state, or NULL on error. Must be free'd by calling wlmtk_titlebar_destroy.

wlmtk_titlebar_destroy()

void wlmtk_titlebar_destroy

(

wlmtk_titlebar_t *

titlebar_ptr

)

Destroys the title bar.

Parameters

titlebar_ptr

wlmtk_titlebar_element()

wlmtk_element_t * wlmtk_titlebar_element

(

wlmtk_titlebar_t *

titlebar_ptr

)

Returns the super Element of the titlebar.

Parameters

titlebar_ptr

Returns

Pointer to the wlmtk_element_t base instantiation to titlebar_ptr.

wlmtk_titlebar_is_activated()

bool wlmtk_titlebar_is_activated

(

wlmtk_titlebar_t *

titlebar_ptr

)

Returns whether the title bar is activated.

wlmtk_titlebar_set_activated()

void wlmtk_titlebar_set_activated	(	wlmtk_titlebar_t *	titlebar_ptr,
		bool	activated
	)

Sets whether the title bar is activated.

Parameters

titlebar_ptr
activated

wlmtk_titlebar_set_properties()

void wlmtk_titlebar_set_properties	(	wlmtk_titlebar_t *	titlebar_ptr,
		uint32_t	properties
	)

Sets the properties of the title bar.

Parameters

titlebar_ptr
properties	See wlmtk_titlebar_property_t.

wlmtk_titlebar_set_style()

bool wlmtk_titlebar_set_style	(	wlmtk_titlebar_t *	titlebar_ptr,
		const struct wlmtk_titlebar_style *	style_ptr
	)

Sets the style of the title bar.

Parameters

titlebar_ptr
style_ptr

Returns

true on success.

wlmtk_titlebar_set_title()

void wlmtk_titlebar_set_title	(	wlmtk_titlebar_t *	titlebar_ptr,
		const char *	title_ptr
	)

Updates the title text of the titlebar.

Parameters

titlebar_ptr
title_ptr	Expected to remain valid until the next call of wlmtk_titlebar_set_title or until the titlebar_ptr is destroyed.

wlmtk_titlebar_set_width()

bool wlmtk_titlebar_set_width	(	wlmtk_titlebar_t *	titlebar_ptr,
		unsigned	width
	)

Sets the width of the title bar.

Parameters

titlebar_ptr
width

Returns

Whether the operation was successful.

Variable Documentation

_wlmtk_titlebar_default_properties

const uint32_t _wlmtk_titlebar_default_properties

static

Initial value:

=
    WLMTK_TITLEBAR_PROPERTY_ICONIFY |
    WLMTK_TITLEBAR_PROPERTY_CLOSE

Default properties: All buttons shown.

_wlmtk_titlebar_test_cases

const bs_test_case_t _wlmtk_titlebar_test_cases[]

static

Initial value:

= {
    { 1, "variable_width", test_variable_width },
    { 1, "properties", test_properties },

}

Test cases

titlebar_element_vmt

const wlmtk_element_vmt_t titlebar_element_vmt

static

Initial value:

= {
    .destroy = _wlmtk_titlebar_element_destroy
}

Virtual method table extension for the titlebar's element superclass.

wlmtk_titlebar_style_desc

const bspl_desc_t wlmtk_titlebar_style_desc[]

Initial value:

= {
    BSPL_DESC_CUSTOM(
        "FocussedFill", true, struct wlmtk_titlebar_style, focussed_fill,
        focussed_fill, wlmtk_style_decode_fill, NULL, NULL, NULL),
    BSPL_DESC_ARGB32(
        "FocussedTextColor", true, struct wlmtk_titlebar_style,
        focussed_text_color, focussed_text_color, 0),
    BSPL_DESC_CUSTOM(
        "BlurredFill", true, struct wlmtk_titlebar_style, blurred_fill,
        blurred_fill, wlmtk_style_decode_fill, NULL, NULL, NULL),
    BSPL_DESC_ARGB32(
        "BlurredTextColor", true, struct wlmtk_titlebar_style,
        blurred_text_color, blurred_text_color, 0),
    BSPL_DESC_UINT64(
        "Height", true, struct wlmtk_titlebar_style, height, height, 22),
    BSPL_DESC_UINT64(
        "BezelWidth", true, struct wlmtk_titlebar_style,
        bezel_width, bezel_width, 1),
    BSPL_DESC_DICT(
        "Margin", true, struct wlmtk_titlebar_style, margin, margin,
        wlmtk_style_margin_desc),
    BSPL_DESC_DICT(
        "Font", true, struct wlmtk_titlebar_style, font, font,
        wlmtk_style_font_desc),

}

Descriptor for decoding the "TitleBar" dict below "Window".

wlmtk_titlebar_test_set

const bs_test_set_t wlmtk_titlebar_test_set

Initial value:

= BS_TEST_SET(
    true, "titlebar", _wlmtk_titlebar_test_cases)

Unit test cases.
