#include <libbase/libbase.h>
#include <stdbool.h>
#include <stdint.h>
#include <wayland-server-core.h>
#include "element.h"
#include "menu.h"
#include "style.h"
#include "util.h"
#include "workspace.h"

Include dependency graph for window.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	wlmtk_window_events_t

Typedefs
typedef struct _wlmtk_window_t	wlmtk_window_t

Enumerations
enum	wlmtk_window_property_t { WLMTK_WINDOW_PROPERTY_RESIZABLE = UINT32_C(1) << 0 , WLMTK_WINDOW_PROPERTY_ICONIFIABLE = UINT32_C(1) << 1 , WLMTK_WINDOW_PROPERTY_CLOSABLE = UINT32_C(1) << 2 , WLMTK_WINDOW_PROPERTY_RIGHTCLICK = UINT32_C(1) << 3 }

Functions
wlmtk_window_t *	wlmtk_window_create (wlmtk_element_t content_element_ptr, const wlmtk_window_style_t style_ptr, const wlmtk_menu_style_t *menu_style_ptr)

void	wlmtk_window_destroy (wlmtk_window_t *window_ptr)

wlmtk_window_events_t *	wlmtk_window_events (wlmtk_window_t *window_ptr)

wlmtk_element_t *	wlmtk_window_element (wlmtk_window_t *window_ptr)

wlmtk_window_t *	wlmtk_window_from_element (wlmtk_element_t *element_ptr)

struct wlr_box	wlmtk_window_get_bounding_box (wlmtk_window_t *window_ptr)

void	wlmtk_window_position_changed (wlmtk_window_t *window_ptr)

void	wlmtk_window_set_properties (wlmtk_window_t *window_ptr, uint32_t properties)

void	wlmtk_window_set_client (wlmtk_window_t window_ptr, const wlmtk_util_client_t client_ptr)

const wlmtk_util_client_t *	wlmtk_window_get_client_ptr (wlmtk_window_t *window_ptr)

void	wlmtk_window_set_wlr_output (wlmtk_window_t window_ptr, struct wlr_output wlr_output_ptr)

struct wlr_output *	wlmtk_window_get_wlr_output (wlmtk_window_t *window_ptr)

bool	wlmtk_window_set_title (wlmtk_window_t window_ptr, const char title_ptr)

const char *	wlmtk_window_get_title (wlmtk_window_t *window_ptr)

void	wlmtk_window_set_activated (wlmtk_window_t *window_ptr, bool activated)

bool	wlmtk_window_is_activated (wlmtk_window_t *window_ptr)

void	wlmtk_window_request_size (wlmtk_window_t window_ptr, const struct wlr_box box_ptr)

void	wlmtk_window_commit_size (wlmtk_window_t *window_ptr, int width, int height)

struct wlr_box	wlmtk_window_get_size (wlmtk_window_t *window_ptr)

void	wlmtk_window_set_resize_edges (wlmtk_window_t *window_ptr, uint32_t edges)

uint32_t	wlmtk_window_get_resize_edges (wlmtk_window_t *window_ptr)

void	wlmtk_window_request_close (wlmtk_window_t *window_ptr)

void	wlmtk_window_request_minimize (wlmtk_window_t *window_ptr)

void	wlmtk_window_request_fullscreen (wlmtk_window_t *window_ptr, bool fullscreen)

bool	wlmtk_window_is_fullscreen (wlmtk_window_t *window_ptr)

void	wlmtk_window_commit_fullscreen (wlmtk_window_t *window_ptr, bool fullscreen)

void	wlmtk_window_request_maximized (wlmtk_window_t *window_ptr, bool maximized)

bool	wlmtk_window_is_maximized (wlmtk_window_t *window_ptr)

void	wlmtk_window_commit_maximized (wlmtk_window_t *window_ptr, bool maximized)

void	wlmtk_window_request_shaded (wlmtk_window_t *window_ptr, bool shaded)

bool	wlmtk_window_is_shaded (wlmtk_window_t *window_ptr)

void	wlmtk_window_menu_set_enabled (wlmtk_window_t *window_ptr, bool enabled)

wlmtk_menu_t *	wlmtk_window_menu (wlmtk_window_t *window_ptr)

void	wlmtk_window_set_server_side_decorated (wlmtk_window_t *window_ptr, bool decorated)

void	wlmtk_window_set_workspace (wlmtk_window_t window_ptr, wlmtk_workspace_t workspace_ptr)

wlmtk_workspace_t *	wlmtk_window_get_workspace (wlmtk_window_t *window_ptr)

bs_dllist_node_t *	wlmtk_dlnode_from_window (wlmtk_window_t *window_ptr)

wlmtk_window_t *	wlmtk_window_from_dlnode (bs_dllist_node_t *dlnode_ptr)

wlmtk_window_t *	wlmtk_test_window_create (wlmtk_element_t *content_element_ptr)

Variables
const bs_test_case_t	wlmtk_window_test_cases []

Detailed Description

Copyright: Copyright 2025 Google LLC

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at

https://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

Typedef Documentation

◆ wlmtk_window_t

typedef struct _wlmtk_window_t wlmtk_window_t

Forward declaration: Window.

Enumeration Type Documentation

◆ wlmtk_window_property_t

enum wlmtk_window_property_t

Window properties.

Enumerator
WLMTK_WINDOW_PROPERTY_RESIZABLE	Can be resized. Server-side decorations will show resize-bar.
WLMTK_WINDOW_PROPERTY_ICONIFIABLE	Can be iconified. Server-side decorations include icnonify button.
WLMTK_WINDOW_PROPERTY_CLOSABLE	Can be closed. Server-side decorations include close button.
WLMTK_WINDOW_PROPERTY_RIGHTCLICK	Kludge: a window that closes on right-click-release. The window's element must pointer_grab. TODO(kaese.nosp@m.r@gu.nosp@m.bbe.c.nosp@m.h): This should be... better.

Function Documentation

◆ wlmtk_dlnode_from_window()

bs_dllist_node_t * wlmtk_dlnode_from_window ( wlmtk_window_t * window_ptr )

Returns: pointer to wlmtk_window_t::dlnode.

◆ wlmtk_test_window_create()

wlmtk_window_t * wlmtk_test_window_create ( wlmtk_element_t * content_element_ptr )

Creates a window, with default styles, for testing.

Parameters

content_element_ptr

Returns: See wlmtk_window_create.

◆ wlmtk_window_commit_fullscreen()

void wlmtk_window_commit_fullscreen	(	wlmtk_window_t *	window_ptr,
		bool	fullscreen
	)

Commits the window as fullscreen: Client has comitted the surface in fullscreen state.

Parameters

window_ptr
fullscreen

◆ wlmtk_window_commit_maximized()

void wlmtk_window_commit_maximized	(	wlmtk_window_t *	window_ptr,
		bool	maximized
	)

Commits the maximized mode for the window.

The call is idempotent: Once the window is committed, further calls with the same maximized value will return straight away.

Parameters

window_ptr
maximized

◆ wlmtk_window_commit_size()

void wlmtk_window_commit_size	(	wlmtk_window_t *	window_ptr,
		int	width,
		int	height
	)

Sets the window's committed size. Should be called when the content size is changed, eg. on surface commit.

Parameters

window_ptr
width
height

◆ wlmtk_window_create()

wlmtk_window_t * wlmtk_window_create	(	wlmtk_element_t *	content_element_ptr,
		const wlmtk_window_style_t *	style_ptr,
		const wlmtk_menu_style_t *	menu_style_ptr
	)

Creates a window.

Parameters

content_element_ptr
style_ptr
menu_style_ptr

Returns: The window handle, or NULL on error.

◆ wlmtk_window_destroy()

void wlmtk_window_destroy ( wlmtk_window_t * window_ptr )

Destroys the window.

Parameters

window_ptr

◆ wlmtk_window_element()

wlmtk_element_t * wlmtk_window_element ( wlmtk_window_t * window_ptr )

Returns the element for adding the window into a container.

Parameters

window_ptr

Returns: Pointer to the super element of wlmtk_window_t::bordered.

◆ wlmtk_window_events()

wlmtk_window_events_t * wlmtk_window_events ( wlmtk_window_t * window_ptr )

Gets the set of events available to a window, for binding listeners.

Parameters

window_ptr

Returns: Pointer to this window's wlmtk_window_t::events.

◆ wlmtk_window_from_dlnode()

wlmtk_window_t * wlmtk_window_from_dlnode ( bs_dllist_node_t * dlnode_ptr )

Returns: the wlmtk_window_t for wlmtk_window_t::dlnode.

◆ wlmtk_window_from_element()

wlmtk_window_t * wlmtk_window_from_element ( wlmtk_element_t * element_ptr )

Returns the window, where element_ptr is wlmtk_window_element.

Parameters

element_ptr

Returns: the wlmtk_window_t from the element pointer.

◆ wlmtk_window_get_bounding_box()

struct wlr_box wlmtk_window_get_bounding_box ( wlmtk_window_t * window_ptr )

Returns the bounding box for the window.

Parameters

window_ptr

Returns: the box.

◆ wlmtk_window_get_client_ptr()

const wlmtk_util_client_t * wlmtk_window_get_client_ptr ( wlmtk_window_t * window_ptr )

Returns a pointer to wlmtk_window_t::client.

Parameters

window_ptr

Returns: Client information. Remains walid until window_ptr is destroyed.

◆ wlmtk_window_get_resize_edges()

uint32_t wlmtk_window_get_resize_edges ( wlmtk_window_t * window_ptr )

Returns: resizing edges.

◆ wlmtk_window_get_size()

struct wlr_box wlmtk_window_get_size ( wlmtk_window_t * window_ptr )

Returns the window's (committed) size. That may be different than the dimensions of the window's wlmtk_window_t::content_element_ptr.

Parameters

window_ptr

Returns: The size box. Only width and height will be used.

◆ wlmtk_window_get_title()

const char * wlmtk_window_get_title ( wlmtk_window_t * window_ptr )

Returns the title of the window.

Parameters

window_ptr

Returns: Pointer to the window title. Will remain valid until the next call to wlmtk_window_set_title, or until the window is destroyed. Will never be NULL.

◆ wlmtk_window_get_wlr_output()

struct wlr_output * wlmtk_window_get_wlr_output ( wlmtk_window_t * window_ptr )

Gets the struct wlr_output that the window prefers, or is on.

Parameters

window_ptr

Returns: Pointer to the struct wlr_output the center of the window is placed on, or NULL if none is available or the window is not mapped.

◆ wlmtk_window_get_workspace()

wlmtk_workspace_t * wlmtk_window_get_workspace ( wlmtk_window_t * window_ptr )

Returns: The value of wlmtk_window_t::workspace_ptr.

◆ wlmtk_window_is_activated()

bool wlmtk_window_is_activated ( wlmtk_window_t * window_ptr )

Returns: whether the window is currently activated.

◆ wlmtk_window_is_fullscreen()

bool wlmtk_window_is_fullscreen ( wlmtk_window_t * window_ptr )

Returns: whether the window currently is in fullscreen mode.

◆ wlmtk_window_is_maximized()

bool wlmtk_window_is_maximized ( wlmtk_window_t * window_ptr )

Returns: whether the window currently is in maximized mode.

◆ wlmtk_window_is_shaded()

bool wlmtk_window_is_shaded ( wlmtk_window_t * window_ptr )

Returns: whether the window currently is shaded.

◆ wlmtk_window_menu()

wlmtk_menu_t * wlmtk_window_menu ( wlmtk_window_t * window_ptr )

Returns a pointer to the window menu's state.

Parameters

window_ptr

Returns: A pointer to the wlmtk_menu_t of the window menu.

◆ wlmtk_window_menu_set_enabled()

void wlmtk_window_menu_set_enabled	(	wlmtk_window_t *	window_ptr,
		bool	enabled
	)

En-/Disables the window menu.

Parameters

window_ptr
enabled

◆ wlmtk_window_position_changed()

void wlmtk_window_position_changed ( wlmtk_window_t * window_ptr )

Helper: Indicates that the position has changed.

◆ wlmtk_window_request_close()

void wlmtk_window_request_close ( wlmtk_window_t * window_ptr )

Requests to close the window.

Parameters

window_ptr

◆ wlmtk_window_request_fullscreen()

void wlmtk_window_request_fullscreen	(	wlmtk_window_t *	window_ptr,
		bool	fullscreen
	)

Requests the window to be fullscreen (or end fullscreen).

Parameters

window_ptr
fullscreen

◆ wlmtk_window_request_maximized()

void wlmtk_window_request_maximized	(	wlmtk_window_t *	window_ptr,
		bool	maximized
	)

Requests the window to be maximized (or end maximized).

Guarantees to emit a wlmtk_window_events_t::request_maximized signal, either with the provided maximized value, or with what the compositor deems acceptable.

Parameters

window_ptr
maximized

◆ wlmtk_window_request_minimize()

void wlmtk_window_request_minimize ( wlmtk_window_t * window_ptr )

Requests to minimize (iconify) the window.

Parameters

window_ptr

◆ wlmtk_window_request_shaded()

void wlmtk_window_request_shaded	(	wlmtk_window_t *	window_ptr,
		bool	shaded
	)

Requests the window to be shaded (rolled up) or not.

Parameters

window_ptr
shaded

◆ wlmtk_window_request_size()

void wlmtk_window_request_size	(	wlmtk_window_t *	window_ptr,
		const struct wlr_box *	box_ptr
	)

Requests the window's size to be updated.

Parameters

window_ptr
box_ptr	Only the `width` and `height` are considered.

◆ wlmtk_window_set_activated()

void wlmtk_window_set_activated	(	wlmtk_window_t *	window_ptr,
		bool	activated
	)

Sets the window as activated, depending on the argument's value.

An activated window will have keyboard focus and would have distinct decorations to indicate state.

Parameters

window_ptr
activated

◆ wlmtk_window_set_client()

void wlmtk_window_set_client	(	wlmtk_window_t *	window_ptr,
		const wlmtk_util_client_t *	client_ptr
	)

Sets client information for the window.

Parameters

window_ptr
client_ptr	The client's information will be copied into wlmtk_window_t::client, and does not need to outlive this call.

◆ wlmtk_window_set_properties()

void wlmtk_window_set_properties	(	wlmtk_window_t *	window_ptr,
		uint32_t	properties
	)

Sets properties for the window.

Parameters

window_ptr
properties

See also: wlmtk_window_property_t.

◆ wlmtk_window_set_resize_edges()

void wlmtk_window_set_resize_edges	(	wlmtk_window_t *	window_ptr,
		uint32_t	edges
	)

Sets the resizing edges. Keeps the opposite edges firm when resizing.

Parameters

window_ptr
edges

◆ wlmtk_window_set_server_side_decorated()

void wlmtk_window_set_server_side_decorated	(	wlmtk_window_t *	window_ptr,
		bool	decorated
	)

Sets whether to have server-side decorations for this window.

Parameters

window_ptr
decorated

◆ wlmtk_window_set_title()

bool wlmtk_window_set_title	(	wlmtk_window_t *	window_ptr,
		const char *	title_ptr
	)

Sets the title for the window.

If title_ptr is NULL, a generic name is set.

Parameters

window_ptr
title_ptr	May be NULL.

Returns: true on success.

◆ wlmtk_window_set_wlr_output()

void wlmtk_window_set_wlr_output	(	wlmtk_window_t *	window_ptr,
		struct wlr_output *	wlr_output_ptr
	)

Sets the WLR output for the window. Used for fullscreen requests.

Parameters

window_ptr
wlr_output_ptr	Output to consider when requesting a window as fullscreen. Can be NULL to indicate no preference.

◆ wlmtk_window_set_workspace()

void wlmtk_window_set_workspace	(	wlmtk_window_t *	window_ptr,
		wlmtk_workspace_t *	workspace_ptr
	)

Sets wlmtk_window_t::workspace_ptr.

Protected method, to be called only from wlmtk_workspace_t.

Parameters

window_ptr
workspace_ptr

Variable Documentation

◆ wlmtk_window_test_cases

const bs_test_case_t wlmtk_window_test_cases[]

extern

Window unit test cases.

Classes

Typedefs

Enumerations

Functions

Variables

Detailed Description

Typedef Documentation

◆ wlmtk_window_t

Enumeration Type Documentation

◆ wlmtk_window_property_t

Function Documentation

◆ wlmtk_dlnode_from_window()

◆ wlmtk_test_window_create()

◆ wlmtk_window_commit_fullscreen()

◆ wlmtk_window_commit_maximized()

◆ wlmtk_window_commit_size()

◆ wlmtk_window_create()

◆ wlmtk_window_destroy()

◆ wlmtk_window_element()

◆ wlmtk_window_events()

◆ wlmtk_window_from_dlnode()

◆ wlmtk_window_from_element()

◆ wlmtk_window_get_bounding_box()

◆ wlmtk_window_get_client_ptr()

◆ wlmtk_window_get_resize_edges()

◆ wlmtk_window_get_size()

◆ wlmtk_window_get_title()

◆ wlmtk_window_get_wlr_output()

◆ wlmtk_window_get_workspace()

◆ wlmtk_window_is_activated()

◆ wlmtk_window_is_fullscreen()

◆ wlmtk_window_is_maximized()

◆ wlmtk_window_is_shaded()

◆ wlmtk_window_menu()

◆ wlmtk_window_menu_set_enabled()

◆ wlmtk_window_position_changed()

◆ wlmtk_window_request_close()

◆ wlmtk_window_request_fullscreen()

◆ wlmtk_window_request_maximized()

◆ wlmtk_window_request_minimize()

◆ wlmtk_window_request_shaded()

◆ wlmtk_window_request_size()

◆ wlmtk_window_set_activated()

◆ wlmtk_window_set_client()

◆ wlmtk_window_set_properties()

◆ wlmtk_window_set_resize_edges()

◆ wlmtk_window_set_server_side_decorated()

◆ wlmtk_window_set_title()

◆ wlmtk_window_set_wlr_output()

◆ wlmtk_window_set_workspace()

Variable Documentation

◆ wlmtk_window_test_cases
