xdg_toplevel.c File Reference

#include "xdg_toplevel.h"
#include <libbase/libbase.h>
#include <stdbool.h>
#include <stdint.h>
#include <stdlib.h>
#include <wayland-server-core.h>
#include <wayland-server-protocol.h>
#include <wayland-server.h>
#include <wlr/types/wlr_compositor.h>
#include <wlr/types/wlr_output.h>
#include <wlr/types/wlr_output_layout.h>
#include <wlr/types/wlr_scene.h>
#include <wlr/types/wlr_xdg_shell.h>
#include <wlr/util/box.h>
#include "server.h"
#include "tl_menu.h"
#include "toolkit/toolkit.h"
#include "xdg_popup.h"

Include dependency graph for xdg_toplevel.c:

Classes
struct	wlmaker_xdg_toplevel
struct	_wlmaker_test_layout
struct	_xdg_toplevel_test_data

Functions
struct wlmaker_xdg_toplevel *	_wlmaker_xdg_toplevel_create_injected (struct wlr_xdg_toplevel *wlr_xdg_toplevel_ptr, wlmaker_server_t *server_ptr, uint32_t(*_set_maximized)(struct wlr_xdg_toplevel *, bool), uint32_t(*_set_fullscreen)(struct wlr_xdg_toplevel *, bool), uint32_t(*_set_size)(struct wlr_xdg_toplevel *, int32_t, int32_t), uint32_t(*_set_activated)(struct wlr_xdg_toplevel *, bool))
static void	_wlmaker_xdg_toplevel_flush_properties (struct wlmaker_xdg_toplevel *wxt_ptr)
static void	_wlmaker_xdg_toplevel_handle_destroy (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_request_maximize (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_request_fullscreen (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_request_minimize (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_request_move (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_request_resize (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_request_show_window_menu (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_set_parent (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_set_title (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_set_app_id (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_new_popup (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_surface_map (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_surface_unmap (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_surface_commit (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_window_request_close (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_window_set_activated (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_window_request_size (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_window_request_fullscreen (struct wl_listener *listener_ptr, void *data_ptr)
static void	_wlmaker_xdg_toplevel_handle_window_request_maximized (struct wl_listener *listener_ptr, void *data_ptr)
struct wlmaker_xdg_toplevel *	wlmaker_xdg_toplevel_create (struct wlr_xdg_toplevel *wlr_xdg_toplevel_ptr, wlmaker_server_t *server_ptr)
void	wlmaker_xdg_toplevel_destroy (struct wlmaker_xdg_toplevel *wxt_ptr)
void	wlmaker_xdg_toplevel_set_server_side_decorated (struct wlmaker_xdg_toplevel *wlmaker_xdg_toplevel_ptr, bool server_side_decorated)
static bool	_wlmaker_test_layout_init (struct _wlmaker_test_layout *tl_ptr)
static void	_wlmaker_test_layout_fini (struct _wlmaker_test_layout *tl_ptr)
uint32_t	_wlmaker_xdg_toplevel_fake_set_maximized (struct wlr_xdg_toplevel *wlr_xdg_toplevel_ptr, bool maximized)
uint32_t	_wlmaker_xdg_toplevel_fake_set_fullscreen (struct wlr_xdg_toplevel *wlr_xdg_toplevel_ptr, bool fullscreen)
uint32_t	_wlmaker_xdg_toplevel_fake_set_size (struct wlr_xdg_toplevel *wlr_xdg_toplevel_ptr, int32_t width, int32_t height)
uint32_t	_wlmaker_xdg_toplevel_fake_set_activated (struct wlr_xdg_toplevel *wlr_xdg_toplevel_ptr, bool activated)
static void *	_wlmaker_xdg_toplevel_test_setup (void)
static void	_wlmaker_xdg_toplevel_test_teardown (void *test_context_ptr)
static void	_wlmaker_xdg_toplevel_test_maximize (bs_test_t *test_ptr)
static void	_wlmaker_xdg_toplevel_test_fullscreen (bs_test_t *test_ptr)
static void	_wlmaker_xdg_toplevel_test_size (bs_test_t *test_ptr)
static void	_wlmaker_xdg_toplevel_test_activated (bs_test_t *test_ptr)

Variables
const bs_test_case_t	_test_cases []
const bs_test_set_t	wlmaker_xdg_toplevel_test_set

Detailed Description

Copyright

Copyright 2023 Google LLC

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at

https://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

Function Documentation

_wlmaker_test_layout_fini()

void _wlmaker_test_layout_fini ( struct _wlmaker_test_layout *  tl_ptr )

static

Un-initializes _wlmaker_test_layout

_wlmaker_test_layout_init()

bool _wlmaker_test_layout_init ( struct _wlmaker_test_layout *  tl_ptr )

static

Initializes _wlmaker_test_layout

_wlmaker_xdg_toplevel_create_injected()

struct wlmaker_xdg_toplevel * _wlmaker_xdg_toplevel_create_injected	(	struct wlr_xdg_toplevel *	wlr_xdg_toplevel_ptr,
		wlmaker_server_t *	server_ptr,
		uint32_t(*)(struct wlr_xdg_toplevel *, bool)	_set_maximized,
		uint32_t(*)(struct wlr_xdg_toplevel *, bool)	_set_fullscreen,
		uint32_t(*)(struct wlr_xdg_toplevel *, int32_t, int32_t)	_set_size,
		uint32_t(*)(struct wlr_xdg_toplevel *, bool)	_set_activated
	)

Creates the toplevel, permitting injected calls to set properties.

_wlmaker_xdg_toplevel_fake_set_activated()

uint32_t _wlmaker_xdg_toplevel_fake_set_activated	(	struct wlr_xdg_toplevel *	wlr_xdg_toplevel_ptr,
		bool	activated
	)

A fake for wlr_xdg_toplevel_set_activated(). Recods the call.

_wlmaker_xdg_toplevel_fake_set_fullscreen()

uint32_t _wlmaker_xdg_toplevel_fake_set_fullscreen	(	struct wlr_xdg_toplevel *	wlr_xdg_toplevel_ptr,
		bool	fullscreen
	)

A fake for wlr_xdg_toplevel_set_fullscreen(). Records the call.

_wlmaker_xdg_toplevel_fake_set_maximized()

uint32_t _wlmaker_xdg_toplevel_fake_set_maximized	(	struct wlr_xdg_toplevel *	wlr_xdg_toplevel_ptr,
		bool	maximized
	)

A fake for wlr_xdg_toplevel_set_maximized(). Records the call.

_wlmaker_xdg_toplevel_fake_set_size()

uint32_t _wlmaker_xdg_toplevel_fake_set_size	(	struct wlr_xdg_toplevel *	wlr_xdg_toplevel_ptr,
		int32_t	width,
		int32_t	height
	)

A fake for wlr_xdg_toplevel_set_size(). Recods the call.

_wlmaker_xdg_toplevel_flush_properties()

void _wlmaker_xdg_toplevel_flush_properties ( struct wlmaker_xdg_toplevel *  wxt_ptr )

static

Sends pending properties as configure() to the client, after 1st commit.

If the first commit hasn't happened yet, the properties will not be sent. A later call to _wlmaker_xdg_toplevel_flush_properties will then flush them. See wlmaker_xdg_toplevel::pending.

Parameters

wxt_ptr

_wlmaker_xdg_toplevel_handle_destroy()

void _wlmaker_xdg_toplevel_handle_destroy ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel is destroyed: Destry the wlmaker toplevel, too.

_wlmaker_xdg_toplevel_handle_new_popup()

void _wlmaker_xdg_toplevel_handle_new_popup ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel adds a new popup.

_wlmaker_xdg_toplevel_handle_request_fullscreen()

void _wlmaker_xdg_toplevel_handle_request_fullscreen ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel (client) requests to be put in fullscreen.

_wlmaker_xdg_toplevel_handle_request_maximize()

void _wlmaker_xdg_toplevel_handle_request_maximize ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel requests to be maximized.

_wlmaker_xdg_toplevel_handle_request_minimize()

void _wlmaker_xdg_toplevel_handle_request_minimize ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel requests to be minimized.

_wlmaker_xdg_toplevel_handle_request_move()

void _wlmaker_xdg_toplevel_handle_request_move ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel requests to be moved.

_wlmaker_xdg_toplevel_handle_request_resize()

void _wlmaker_xdg_toplevel_handle_request_resize ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel requests to be resized.

_wlmaker_xdg_toplevel_handle_request_show_window_menu()

void _wlmaker_xdg_toplevel_handle_request_show_window_menu ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel requests to show the window menu.

_wlmaker_xdg_toplevel_handle_set_app_id()

void _wlmaker_xdg_toplevel_handle_set_app_id ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel sets the app ID.

_wlmaker_xdg_toplevel_handle_set_parent()

void _wlmaker_xdg_toplevel_handle_set_parent ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel sets the parent.

_wlmaker_xdg_toplevel_handle_set_title()

void _wlmaker_xdg_toplevel_handle_set_title ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

The XDG toplevel sets the title.

_wlmaker_xdg_toplevel_handle_surface_commit()

void _wlmaker_xdg_toplevel_handle_surface_commit ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles XDG surface commits.

_wlmaker_xdg_toplevel_handle_surface_map()

void _wlmaker_xdg_toplevel_handle_surface_map ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles the XDG's surface map event.

_wlmaker_xdg_toplevel_handle_surface_unmap()

void _wlmaker_xdg_toplevel_handle_surface_unmap ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles when the XDG surface is to be unmapped.

_wlmaker_xdg_toplevel_handle_window_request_close()

void _wlmaker_xdg_toplevel_handle_window_request_close ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles the window's request_close event: Forwards to the toplevel.

_wlmaker_xdg_toplevel_handle_window_request_fullscreen()

void _wlmaker_xdg_toplevel_handle_window_request_fullscreen ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles the window's request for going to fullscreen.

_wlmaker_xdg_toplevel_handle_window_request_maximized()

void _wlmaker_xdg_toplevel_handle_window_request_maximized ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles the window's request for going to maximized.

_wlmaker_xdg_toplevel_handle_window_request_size()

void _wlmaker_xdg_toplevel_handle_window_request_size ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles the window's request for size.

_wlmaker_xdg_toplevel_handle_window_set_activated()

void _wlmaker_xdg_toplevel_handle_window_set_activated ( struct wl_listener *  listener_ptr, void *  data_ptr  )

static

Handles the window's activation event: Forwards to the toplevel.

_wlmaker_xdg_toplevel_test_activated()

void _wlmaker_xdg_toplevel_test_activated ( bs_test_t *  test_ptr )

static

Tests set_activated requests.

_wlmaker_xdg_toplevel_test_fullscreen()

void _wlmaker_xdg_toplevel_test_fullscreen ( bs_test_t *  test_ptr )

static

Tests fullscreen requests, from client & window.

_wlmaker_xdg_toplevel_test_maximize()

void _wlmaker_xdg_toplevel_test_maximize ( bs_test_t *  test_ptr )

static

Tests maximize requests, from client & window.

_wlmaker_xdg_toplevel_test_setup()

void * _wlmaker_xdg_toplevel_test_setup ( void  )

static

Creates a _xdg_toplevel_test_data in the test context.

_wlmaker_xdg_toplevel_test_size()

void _wlmaker_xdg_toplevel_test_size ( bs_test_t *  test_ptr )

static

Tests set_size requests.

_wlmaker_xdg_toplevel_test_teardown()

void _wlmaker_xdg_toplevel_test_teardown ( void *  test_context_ptr )

static

Tear down XDG toplevel data.

wlmaker_xdg_toplevel_create()

struct wlmaker_xdg_toplevel * wlmaker_xdg_toplevel_create	(	struct wlr_xdg_toplevel *	wlr_xdg_toplevel_ptr,
		wlmaker_server_t *	server_ptr
	)

Creates an XDG toplevel.

Parameters

wlr_xdg_toplevel_ptr
server_ptr

Returns

wlmaker's toplevel handle or NULL on error.

wlmaker_xdg_toplevel_destroy()

void wlmaker_xdg_toplevel_destroy

(

struct wlmaker_xdg_toplevel *

wlmaker_xdg_toplevel_ptr

)

Dtor for the XDG toplevel.

wlmaker_xdg_toplevel_set_server_side_decorated()

void wlmaker_xdg_toplevel_set_server_side_decorated	(	struct wlmaker_xdg_toplevel *	wlmaker_xdg_toplevel_ptr,
		bool	server_side_decorated
	)

En-/Disables server-side decoration for the XDG toplevel.

Variable Documentation

_test_cases

const bs_test_case_t _test_cases[]

Initial value:

= {
    { true, "maximize", _wlmaker_xdg_toplevel_test_maximize },
    { true, "fullscreen", _wlmaker_xdg_toplevel_test_fullscreen },
    { true, "size", _wlmaker_xdg_toplevel_test_size },
    { true, "activated", _wlmaker_xdg_toplevel_test_activated },

}

Unit test cases.

wlmaker_xdg_toplevel_test_set

const bs_test_set_t wlmaker_xdg_toplevel_test_set

Initial value:

= BS_TEST_SET_CONTEXT(
    true,
    "xdg_toplevel",
    _test_cases,
    _wlmaker_xdg_toplevel_test_setup,
    _wlmaker_xdg_toplevel_test_teardown)

Unit test set.
