wlclient.c File Reference

#include "wlclient.h"
#include <errno.h>
#include <inttypes.h>
#include <libbase/libbase.h>
#include <poll.h>
#include <signal.h>
#include <stdarg.h>
#include <stdbool.h>
#include <stddef.h>
#include <stdlib.h>
#include <string.h>
#include <sys/mman.h>
#include <sys/signalfd.h>
#include <sys/types.h>
#include <unistd.h>
#include <wayland-client-core.h>
#include <wayland-client-protocol.h>
#include <wayland-server-core.h>
#include <wayland-util.h>
#include <xkbcommon/xkbcommon.h>
#include "wlmaker-icon-unstable-v1-client-protocol.h"
#include "ext-input-observation-v1-client-protocol.h"
#include "xdg-shell-client-protocol.h"
#include "xdg-decoration-client-protocol.h"
#include "wlr-layer-shell-unstable-v1-client-protocol.h"

Include dependency graph for wlclient.c:

Classes
struct	_wlmcl_client_t
struct	wlmcl_client_timer_t
struct	object_t

Functions
static void	wl_to_bs_log (const char *fmt, va_list args)
static void	handle_global_announce (void *data_ptr, struct wl_registry *wl_registry_ptr, uint32_t name, const char *interface_ptr, uint32_t version)
static void	handle_global_remove (void *data_ptr, struct wl_registry *registry, uint32_t name)
static wlmcl_client_timer_t *	wlmcl_client_timer_create (wlmcl_client_t *client_ptr, uint64_t target_usec, wlmcl_client_callback_t callback, void *callback_ud_ptr)
static void	wlmcl_client_timer_destroy (wlmcl_client_timer_t *timer_ptr)
static void	wlmcl_client_seat_setup (wlmcl_client_t *client_ptr)
static void	wlmcl_client_seat_handle_capabilities (void *data_ptr, struct wl_seat *wl_seat_ptr, uint32_t capabilities)
static void	wlmcl_client_seat_handle_name (void *data_ptr, struct wl_seat *wl_seat_ptr, const char *name_ptr)
static void	wlmcl_client_pointer_handle_enter (void *data, struct wl_pointer *wl_pointer, uint32_t serial, struct wl_surface *surface, wl_fixed_t surface_x, wl_fixed_t surface_y)
static void	wlmcl_client_pointer_handle_leave (void *data, struct wl_pointer *wl_pointer, uint32_t serial, struct wl_surface *surface)
static void	wlmcl_client_pointer_handle_motion (void *data, struct wl_pointer *wl_pointer, uint32_t time, wl_fixed_t surface_x, wl_fixed_t surface_y)
static void	wlmcl_client_pointer_handle_button (void *data, struct wl_pointer *wl_pointer, uint32_t serial, uint32_t time, uint32_t button, uint32_t state)
static void	wlmcl_client_pointer_handle_axis (void *data, struct wl_pointer *wl_pointer, uint32_t time, uint32_t axis, wl_fixed_t value)
static void	wlmcl_client_pointer_handle_frame (void *data, struct wl_pointer *wl_pointer)
static void	wlmcl_client_pointer_handle_axis_source (void *data, struct wl_pointer *wl_pointer, uint32_t axis_source)
static void	wlmcl_client_pointer_handle_axis_stop (void *data, struct wl_pointer *wl_pointer, uint32_t time, uint32_t axis)
static void	wlmcl_client_pointer_handle_axis_discrete (void *data, struct wl_pointer *wl_pointer, uint32_t axis, int32_t discrete)
static void	_wlmcl_client_keyboard_handle_keymap (void *data_ptr, struct wl_keyboard *wl_keyboard_ptr, uint32_t format, int32_t fd, uint32_t size)
static void	_wlmcl_client_keyboard_handle_enter (void *data_ptr, struct wl_keyboard *wl_keyboard_ptr, uint32_t serial, struct wl_surface *wl_surface_ptr, struct wl_array *keys)
static void	_wlmcl_client_keyboard_handle_leave (void *data_ptr, struct wl_keyboard *wl_keyboard_ptr, uint32_t serial, struct wl_surface *wl_surface_ptr)
static void	_wlmcl_client_keyboard_handle_key (void *data_ptr, struct wl_keyboard *wl_keyboard_ptr, uint32_t serial, uint32_t time, uint32_t key, uint32_t state)
static void	_wlmcl_client_keyboard_handle_modifiers (void *data_ptr, struct wl_keyboard *wl_keyboard_ptr, uint32_t serial, uint32_t mods_depressed, uint32_t mods_latched, uint32_t mods_locked, uint32_t group)
static void	_wlmcl_client_keyboard_handle_repeat_info (void *data_ptr, struct wl_keyboard *wl_keyboard_ptr, int32_t rate, int32_t delay)
wlmcl_client_t *	wlmcl_client_create (const char *app_id_ptr)
void	wlmcl_client_destroy (wlmcl_client_t *wlclient_ptr)
const struct wlmcl_client_attributes *	wlmcl_client_attributes (const wlmcl_client_t *wlclient_ptr)
struct wlmcl_client_events *	wlmcl_client_events (wlmcl_client_t *wlclient_ptr)
void	wlmcl_client_run (wlmcl_client_t *wlclient_ptr)
void	wlmcl_client_request_terminate (wlmcl_client_t *wlclient_ptr)
bool	wlmcl_client_register_timer (wlmcl_client_t *wlclient_ptr, uint64_t target_usec, wlmcl_client_callback_t callback, void *callback_ud_ptr)

Variables
static const struct wl_registry_listener	registry_listener
static const struct wl_seat_listener	wlmcl_client_seat_listener
static const struct wl_pointer_listener	wlmcl_client_pointer_listener
static const struct wl_keyboard_listener	wlmcl_client_keyboard_listener
static const object_t	objects []

Detailed Description

Copyright

Copyright (c) 2026 Philipp Kaeser (kaese.nosp@m.r@gu.nosp@m.bbe.c.nosp@m.h) Copyright 2023 Google LLC

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at

https://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

Function Documentation

_wlmcl_client_keyboard_handle_enter()

void _wlmcl_client_keyboard_handle_enter ( void *  data_ptr, struct wl_keyboard *  wl_keyboard_ptr, uint32_t  serial, struct wl_surface *  wl_surface_ptr, struct wl_array *  keys  )

static

Called when the given surface gained keyboard focus.

_wlmcl_client_keyboard_handle_key()

void _wlmcl_client_keyboard_handle_key ( void *  data_ptr, struct wl_keyboard *  wl_keyboard_ptr, uint32_t  serial, uint32_t  time, uint32_t  key, uint32_t  state  )

static

Called when a key was pressed or released.

_wlmcl_client_keyboard_handle_keymap()

void _wlmcl_client_keyboard_handle_keymap ( void *  data_ptr, struct wl_keyboard *  wl_keyboard_ptr, uint32_t  format, int32_t  fd, uint32_t  size  )

static

Called when compositor provides a keymap to memory-map.

_wlmcl_client_keyboard_handle_leave()

void _wlmcl_client_keyboard_handle_leave ( void *  data_ptr, struct wl_keyboard *  wl_keyboard_ptr, uint32_t  serial, struct wl_surface *  wl_surface_ptr  )

static

Called when the given surface lost keyboard focus.

_wlmcl_client_keyboard_handle_modifiers()

void _wlmcl_client_keyboard_handle_modifiers ( void *  data_ptr, struct wl_keyboard *  wl_keyboard_ptr, uint32_t  serial, uint32_t  mods_depressed, uint32_t  mods_latched, uint32_t  mods_locked, uint32_t  group  )

static

Called when the modifier or group state has changed.

_wlmcl_client_keyboard_handle_repeat_info()

void _wlmcl_client_keyboard_handle_repeat_info ( void *  data_ptr, struct wl_keyboard *  wl_keyboard_ptr, int32_t  rate, int32_t  delay  )

static

Called to configure repeat and delay settings.

handle_global_announce()

void handle_global_announce ( void *  data_ptr, struct wl_registry *  wl_registry_ptr, uint32_t  name, const char *  interface_name_ptr, uint32_t  version  )

static

Handles the announcement of a global object.

Called by struct wl_registry_listener global callback, invoked to notify clients of global objects.

Parameters

data_ptr	Points to a wlmcl_client_t.
wl_registry_ptr	The struct wl_registry this is invoked for.
name	Numeric name of the global object.
interface_name_ptr	Name of the interface implemented by the object.
version	Interface version.

handle_global_remove()

void handle_global_remove ( void *  data_ptr, struct wl_registry *  wl_registry_ptr, uint32_t  name  )

static

Handles the removal of a wayland global object.

Called by struct wl_registry_listener global_remove, invoked to notify clients of removed global objects.

Parameters

data_ptr	Points to a wlmcl_client_t.
wl_registry_ptr	The struct wl_registry this is invoked for.
name	Numeric name of the global object.

wl_to_bs_log()

void wl_to_bs_log ( const char *  fmt_ptr, va_list  args  )

static

Redirects a wayland log call into s_log.

Parameters

fmt_ptr
args

wlmcl_client_attributes()

const struct wlmcl_client_attributes * wlmcl_client_attributes

(

const wlmcl_client_t *

wlmcl_client_ptr

)

Gets the client attributes.

Parameters

wlmcl_client_ptr

Returns

A pointer to the attributes.

wlmcl_client_create()

wlmcl_client_t * wlmcl_client_create

(

const char *

app_id_ptr

)

Creates a wayland client for simple buffer interactions.

Parameters

app_id_ptr

Application ID or NULL if not set.

Returns

The client state, or NULL on error. The state needs to be free'd via wlmcl_client_destroy.

wlmcl_client_destroy()

void wlmcl_client_destroy

(

wlmcl_client_t *

wlmcl_client_ptr

)

Destroys the wayland client, as created by wlmcl_client_create.

Parameters

wlmcl_client_ptr

wlmcl_client_events()

struct wlmcl_client_events * wlmcl_client_events

(

wlmcl_client_t *

wlmcl_client_ptr

)

Returns

A pointer to wlmcl_client_t::events.

wlmcl_client_pointer_handle_axis()

void wlmcl_client_pointer_handle_axis ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  time, uint32_t  axis, wl_fixed_t  value  )

static

Called upon axis events.

wlmcl_client_pointer_handle_axis_discrete()

void wlmcl_client_pointer_handle_axis_discrete ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  axis, int32_t  discrete  )

static

Called upon axis click events.

wlmcl_client_pointer_handle_axis_source()

void wlmcl_client_pointer_handle_axis_source ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  axis_source  )

static

Called upon axis source events.

wlmcl_client_pointer_handle_axis_stop()

void wlmcl_client_pointer_handle_axis_stop ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  time, uint32_t  axis  )

static

Axis stop events.

wlmcl_client_pointer_handle_button()

void wlmcl_client_pointer_handle_button ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  serial, uint32_t  time, uint32_t  button, uint32_t  state  )

static

Called upon pointer button events.

wlmcl_client_pointer_handle_enter()

void wlmcl_client_pointer_handle_enter ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  serial, struct wl_surface *  surface, wl_fixed_t  surface_x, wl_fixed_t  surface_y  )

static

Called when the client obtains pointer focus.

wlmcl_client_pointer_handle_frame()

void wlmcl_client_pointer_handle_frame ( void *  data, struct wl_pointer *  wl_pointer  )

static

Called upon frame events.

wlmcl_client_pointer_handle_leave()

void wlmcl_client_pointer_handle_leave ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  serial, struct wl_surface *  surface  )

static

Called when the client looses pointer focus.

wlmcl_client_pointer_handle_motion()

void wlmcl_client_pointer_handle_motion ( void *  data, struct wl_pointer *  wl_pointer, uint32_t  time, wl_fixed_t  surface_x, wl_fixed_t  surface_y  )

static

Called upon pointer motion.

wlmcl_client_register_timer()

bool wlmcl_client_register_timer	(	wlmcl_client_t *	wlmcl_client_ptr,
		uint64_t	target_usec,
		wlmcl_client_callback_t	callback,
		void *	callback_ud_ptr
	)

Registers a timer with the client.

Once the system clock reaches (or has passed) target_usec, callback will be called with the provided arguments. This is a one-time registration. For repeated calls, clients need to re-register.

Parameters

wlmcl_client_ptr
target_usec
callback
callback_ud_ptr

Returns

true on success.

wlmcl_client_request_terminate()

void wlmcl_client_request_terminate

(

wlmcl_client_t *

wlmcl_client_ptr

)

Requests termination of the client-s mainloop. This takes effect only once the mainloop wraps up an iteration.

Parameters

wlmcl_client_ptr

wlmcl_client_run()

void wlmcl_client_run

(

wlmcl_client_t *

wlmcl_client_ptr

)

Runs the client's mainloop.

Parameters

wlmcl_client_ptr

wlmcl_client_seat_handle_capabilities()

void wlmcl_client_seat_handle_capabilities ( void *  data_ptr, struct wl_seat *  wl_seat_ptr, uint32_t  capabilities  )

static

Handles the seat's capability updates.

Un-/Registers listeners for the pointer, if the capability is available.

Parameters

data_ptr
wl_seat_ptr
capabilities

wlmcl_client_seat_handle_name()

void wlmcl_client_seat_handle_name ( void *  data_ptr, struct wl_seat *  wl_seat_ptr, const char *  name_ptr  )

static

Handles the unique identifier callback.

wlmcl_client_seat_setup()

void wlmcl_client_seat_setup ( wlmcl_client_t *  client_ptr )

static

Set up the seat: Registers the client's seat listeners.

wlmcl_client_timer_create()

wlmcl_client_timer_t * wlmcl_client_timer_create ( wlmcl_client_t *  client_ptr, uint64_t  target_usec, wlmcl_client_callback_t  callback, void *  callback_ud_ptr  )

static

Creates a timer and registers it with the client.

Parameters

client_ptr
target_usec
callback
callback_ud_ptr

Returns

A pointer to the created timer, or NULL on error. The pointer must be destroyed by wlmcl_client_timer_destroy.

wlmcl_client_timer_destroy()

void wlmcl_client_timer_destroy ( wlmcl_client_timer_t *  timer_ptr )

static

Destroys the timer. Note: The timer will NOT be unregistered first.

Parameters

timer_ptr

Variable Documentation

objects

const object_t objects[]

static

Initial value:

= {
    { &wl_compositor_interface, 4,
      offsetof(struct wlmcl_client_attributes, wl_compositor_ptr), NULL },
    { &wl_shm_interface, 1,
      offsetof(struct wlmcl_client_attributes, wl_shm_ptr), NULL },
    { &xdg_wm_base_interface, 1,
      offsetof(struct wlmcl_client_attributes, xdg_wm_base_ptr), NULL },
    { &wl_seat_interface, 5,
      offsetof(struct wlmcl_client_attributes, wl_seat_ptr), wlmcl_client_seat_setup },
    { &zwlmaker_icon_manager_v1_interface, 1,
      offsetof(struct wlmcl_client_attributes, icon_manager_ptr), NULL },
    { &zxdg_decoration_manager_v1_interface, 1,
      offsetof(struct wlmcl_client_attributes, xdg_decoration_manager_ptr), NULL },
    { &ext_input_observation_manager_v1_interface, 1,
      offsetof(struct wlmcl_client_attributes, input_observation_manager_ptr), NULL },
    { &zwlr_layer_shell_v1_interface, 4,
      offsetof(struct wlmcl_client_attributes, layer_shell_ptr), NULL },
    { NULL, 0, 0, NULL }

}

List of wayland objects we want to bind to.

registry_listener

const struct wl_registry_listener registry_listener

static

Initial value:

= {
    .global = handle_global_announce,
    .global_remove = handle_global_remove,
}

Listener for the registry, taking note of registry updates.

wlmcl_client_keyboard_listener

const struct wl_keyboard_listener wlmcl_client_keyboard_listener

static

Initial value:

= {
    .keymap = _wlmcl_client_keyboard_handle_keymap,
    .enter = _wlmcl_client_keyboard_handle_enter,
    .leave = _wlmcl_client_keyboard_handle_leave,
    .key = _wlmcl_client_keyboard_handle_key,
    .modifiers = _wlmcl_client_keyboard_handle_modifiers,
    .repeat_info = _wlmcl_client_keyboard_handle_repeat_info
}

Listeners for the keyboard.

wlmcl_client_pointer_listener

const struct wl_pointer_listener wlmcl_client_pointer_listener

static

Initial value:

= {
    .enter = wlmcl_client_pointer_handle_enter,
    .leave = wlmcl_client_pointer_handle_leave,
    .motion = wlmcl_client_pointer_handle_motion,
    .button = wlmcl_client_pointer_handle_button,
    .axis = wlmcl_client_pointer_handle_axis,
    .frame = wlmcl_client_pointer_handle_frame,
    .axis_source = wlmcl_client_pointer_handle_axis_source,
    .axis_stop = wlmcl_client_pointer_handle_axis_stop,
    .axis_discrete = wlmcl_client_pointer_handle_axis_discrete,
}

Listeners for the pointer.

wlmcl_client_seat_listener

const struct wl_seat_listener wlmcl_client_seat_listener

static

Initial value:

= {
    .capabilities = wlmcl_client_seat_handle_capabilities,
    .name = wlmcl_client_seat_handle_name,
}

Listeners for the seat.
